Symbol explanations



Openess Openness factor



Transparent Transparent
Semi-transparent Semi-transparent
Oblique Translucent
Darkening Room
darkening
Weight in gr/m3 Weight in
g/m2 or g/m1
Fabric width Fabric width
Fabric thickness Fabric thickness
Light Fastness Light fastness
Material Composition Material composition
GL Fiberglass
PES Polyester
PET Recycled Polyester
PVC PVC
ROP Recycled plastic from the sea
Trevira CS Tervira CS (flame retardant)
Suitable For Humid Environment Suitable for humid
environments
Flame retardant Flame retardant
Clean with soft brush Clean with soft brush
Clean with sponge Clean with sponge
Clean by hand Clean by hand
Made with welded bottom weights Made with welded bottom weights
Anti static Anti static
Heat reduce class A++, A+ or A+ Heat reduction classification A++, A+ or A+
Insulation class Insulation classification A++, A+ or A
Max height width Max height width
Fabric can be spliced at height Fabric can be spliced at height
OEKO-TEX® 100 certified OEKO-TEX® 100 certified
GREENGUARD certified GREENGUARD certified
Cradle-to-Cradle certified Cradle-to-Cradle certified
Byggvarubedömda vävar Reviewed and accepted by Byggvarubedömningen
Reviewed and categorized with B by SundaHus
Made by recycled material Made by recycled material
Free from PVC Free from PVC
Free from Halogen Free from Halogen
Rv % - Ljusreflektion Procent av ljuset som reflekteras av väven Rv % – Light reflection
Amount of light reflected by fabric
Tv %/Tv total % - Total light transmission Tv %/Tv total % – Total light transmission
Amount of light let trough by fabric
Tv %/Tv total % Tv diff % – Diffuse light transmission
Amount of light filtered by through fabric
Tv dir % - Direct light transmission Tv dir % – Direct light transmission
Amount of light directly passing through fabric
Rs % - Heat reflection Rs % – Heat reflection
Amount of heat reflected by fabric
Ts % - Heat transmission Ts % – Heat transmission
Amount of heat passing through fabric
Tv dir % Tuv % – UV transmission
Amount of UV-light passing through fabric
g-Value G-value = Fabrics total transmission of energy both directly and indirectly. The lower value the lesser energy intake.
– Type A Simple glass 4 mm
– Type B Double glass 4/12/4 mm
– Type D Double glass 4/16/4 mm
Comfort value Thermal comfort = decided by heat transmission, heat reflection and G-value
Glc Possibility to control glare and contrast (from 0-4)

Price groups
(from low to high)
